19
12V, 100W long-life halogen bulb (pre-centered) 12V100WHAL-L (PHILIPS 7724)
12 V, 50 W long-life halogen bulb (pre-centered) 12V50WHAL-L (LIFE JC)
Average life time: Approximately 2000 hr.
Input rating: 100-120 V , 3.0 A, 50/60 Hz
220-240 V , 1.7 A, 50/60 Hz.
Output rating: 2.5-12.6 V DC (continuously variable), max. 8.4 A (12.6 V)
Item Specification
SPECIFICATIONS
Optical system UIS2 (UIS) (Universal Infinity System) optical system
Reflected light illumination
(U-KMAS illuminator)
Tube magnification 1X, super widefield (FN 26.5) compatible.
Available observations: @ Reflected light brightfield
² Reflected light Nomarski DIC
³ Reflected light simplified polarized light
Electrical system
(U-LH100-3 lamp housing, TH4
power supply)
Focusing system
(BXFM-F focusing unit)
Observation tube height movement by roller guide (rack & pinion)
Stroke per rotation: 0.2 mm (fine), 36 mm (coarse)
Full stroke range: 30 mm
Tension adjustment on coarse focus adjustment knob.
Revolving nosepiece U-5RE-2
DIC slider insertion type:
U-D6RE, U-D7RE, (U-D5BDRE, U-D6BDRE) etc.
Motorized revolving nosepieces also applicable.
Observation tube
U-BI30-2
Widefield binocular
U-TR30-2
Widefield trinocular
U-ETR3
Widefield erected
trinocular
U-SWTR-3
Super widefield
trinocular
FN 22 FN 26.5
Tube tilting angle: Fixed
Interpupillary distance adjustment: 50 to 76 mm
Operating environment · Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 5° to 30°C (41° to 86° F)
· Maximum relative humidity: 80% for temperatures up to 31°C (88°F), decreasing linearly
through 70% at 34°C (93°F), 60% at 37°C (99°F), to 50% relative humidity at 40°C (104°F).
· Supply voltage fluctuations: ±10%
· Pollution degree: 2 (in accordance with IEC60664)
· Installation (overvoltage) category: II (in accordance with IEC60664)
