CH10/CH20 C. DISASSEMBLY AND ASSEMBLY PROCEDURES
C-1
1. Focusing Unit
1-1 Base plate and arm
No. Parts name Screw Grease Adhesive Remarks
•
DAIAL
‚
PLATE ACU3X4SA (*1)
ƒ
WASHER OT2008
„
BASE PLATE CUKSK3X6SA (*2) 5
pcs.
HWB3SB (*3)
Remove the base
plate, opening the
lamp cover.
…
ARM AB5X12SA (*4) 3 pcs.
*1
*2
*2
*2
*2
*3
„
•
ƒ
‚
…
*4
