DSX1000
Communication with controller PC
Upright frame
DSX10-UF
Focusing:
Coarse/fine coaxial focusing knob
Stroke: 50 mm
Equipped with function to adjust rotation tension
Motorized control unit:
Control of zoom head DSX10-UZH / DSX10-SZH
Control of LED transmitted light illuminator
DSX10-ILT
Communication with console DSX10-CSL
Communication with controller PC
Lens attachment Lens attachment for XLOB
DSX10-LAXL
Two pieces as one set
Two XLOB objectives can be attached
Lens attachment for UIS
DSX10-LAUIS
Three pieces as one set
Two UIS objectives can be attached
Objective Super long working distance objective lens 1X
DSX10-SXLOB1X
NA0.03, WD51.7
Tiltable angle ±54.3°
Super long working distance objective lens 3X
DSX10-SXLOB3X
NA0.09, WD66.1
Tiltable angle ±60.7°
Super long working distance objective lens 10X
DSX10-SXLOB10X
NA0.20, WD41.1
Tiltable angle ±47.9°
Long working distance objective lens 3X
DSX10-XLOB3X
NA0.09, WD30.0
Tiltable angle ±56.9°
Long working distance objective lens 10X
DSX10-XLOB10X
NA0.30, WD30.0
Tiltable angle ±57.4°
Long working distance objective lens 20X
DSX10-XLOB20X
NA0.40, WD20.0
Tiltable angle ±48.5°
Long working distance objective lens 40X
DSX10-XLOB40X
NA0.80, WD4.5
Tiltable angle ±15.6°
UIS2 objective lens MPLFLN5XBDP NA0.15, WD12.0
UIS2 objective lens MPLFLN10XBDP NA0.25, WD6.5
UIS2 objective lens MPLFLN20XBDP NA0.40, WD3.0
UIS2 objective lens MPLFLN50XBDP NA0.75, WD1.0
UIS2 objective lens LMPLFLN10XBD NA0.25, WD10.0
UIS2 objective lens LMPLFLN20XBD NA0.40, WD12.0
UIS2 objective lens LMPLFLN50XBD NA0.50, WD10.6
UIS2 objective lens MPLAPON50X NA0.95, WD0.35
UIS2 objective lens MPLFLN1.25X NA0.04, WD3.5
UIS2 objective lens MPLFLN2.5X NA0.08, WD10.7
Adapter Diffused illumination adapter for DSX10-
SXLOB1X/10X
DSX10-DIAD1X10X
WD (mm)
DSX10-SXLOB1X: 2.3 to 12.3
DSX10-SXLOB10X: 0 to 1.75
Tiltable angle (°)
DSX10-SXLOB1X: ±6.9 to ±32.9
15
5.1 Hardware5. Specifications
