DSX1000
Experiment total assist software *4
OLS51-S-ETA
Media type: DVD
Storage case Objective lens case
DSX10-LC
Three pieces of lens attachments with objectives
attached can be stored.
Calibration sample Calibration sample
DSX-CALS-HR
P50 (50 µm × 200)
P10 (10 µm × 360)
P3 (3 µm × 300)
Interface board PCIe interface board
DP74-PCIE
PC interface
PCI Express Rev.2.0 x4
Compatible with low profiles
*1: You can select the priority mode either from the stage movable range or the stage rotatable range. (For setting
procedures, see "1.8.3 Selecting the stage priority mode" in Operation Manual).
*2: If the diagonal display size is different, the monitor magnification will be different.
*3: An enhanced analysis application DSX10-S-AA is provided with this product. For those who upgraded from DSX10-BSW
(Version.1.1.x), it is available for a charge.
*4: The experiment total assistance tool of OLS51-S-ETA cannot be used.
5.2 Dimension and weight
Unit Name Dimension (mm) Weight (kg)
Universal zoom head
DSX10-UZH
180(W) x 430(D) x 365(H) 11.0
Standard zoom head
DSX10-SZH
180(W) x 430(D) x 365(H) 10.8
Rotatable motorized XY stage
DSX10-RMTS
220(W) x 245(D) x 105(H)
* Excluding connector, plate and other protrusions
5.9
Motorized XY stage
DSX10-MTS
220(W) x 245(D) x 105(H)
* Excluding connector, plate and other protrusions
5.8
Manual stage
U-SIC4R2
216(W) x 169(D) x 64(H) 1.4
Adapter for manual stage
DSX10-MSTAD
125(W) x 140(D) x 100(H) 4.4
Tilting frame
DSX10-TF
385(W) x 518(D) x 535(H) 18.6
Upright frame
DSX10-UF
385(W) x 518(D) x 395(H) 15.9
Lens attachment for XLOB
DSX10-LAXL
78(W) x 150(D) x 43(H) 0.7
Lens attachment for UIS
DSX10-LAUIS
78(W) x 150(D) x 43(H) 1.2
Super long working distance objective lens 1X
DSX10-SXLOB1X
75.4(W) x 172.5(D) x 94.5(H) 1.0
Super long working distance objective lens 3X
DSX10-SXLOB3X
75.4(W) x 172.5(D) x 80.1(H) 0.8
17
5.2 Dimension and weight5. Specifications
