Olympus E-PL1 User Manual

8 EN
Basic guide
Names of parts and functions
Camera
1
2
3
4
5
7
6
b
9
a
0
4
8
f
c
d
e
g
h
1 Mode dial................................ P. 6, 10
2 Shutter button ................ P. 11, 12, 46
3 ON/OFF button............................. P. 6
4 Strap eyelet ..................................P. 2
5 Self-timer lamp ...........................P. 30
6 Lens attachment mark ................. P. 5
7 Mount (Remove the body cap before
attaching the lens.)
8 Microphone ..........................P. 57, 65
9 Hot shoe cover
0 Built-in fl ash................................P. 54
a Lens release button .....................P. 5
b Lens lock pin
c Tripod socket
d Battery/card compartment cover
.....................................................P. 3
e Battery/card compartment lock ....P. 3
f Connector cover
g Multi-connector...............P. 67, 84, 87
h HDMI mini-connector (type C).... P. 67
Names of parts and functions
S0027E.indb8S0027E.indb8 2009/12/2114:52:382009/12/2114:52:38

Olympus E-PL1 Specifications

General

Brand	Olympus
Model	E-PL1
Category	Digital Camera
Language	English
