Olympus FE-4020 User Manual

34 EN
Selecting the camera sound and its volume [SOUND SETTINGS]
s (Settings 2) X SOUND SETTINGS
Submenu 2 Submenu 3 Submenu 4 Application
SILENT MODE
*1, 2
OFF/ON —
Select [ON] to disable camera sounds
(operating sound, shutter sound, and warning
sound) and mute sound during playback.
BEEP
SOUND TYPE
1/2/3
Selects the operating sound and volume
of the camera buttons (except the shutter
button).
VOLUME
OFF (No Sound) or
2 levels of volume
SHUTTER SOUND
SOUND TYPE
1/2/3
Selects the type and volume of the shutter
sound.
VOLUME
OFF (No Sound) or
2 levels of volume
8
OFF (No Sound) or
2 levels of volume
— Adjusts the warning sound volume.
q VOLUME
OFF (No Sound) or
5 levels of volume
— Adjusts the image playback volume.
*1
Even when [SILENT MODE] is [ON], FG can be used to adjust volume during playback.
*2
Even when [SILENT MODE] is [ON], sound is played when images are displayed on a television.
Adjusting the CCD and the image
processing function [PIXEL MAPPING]
s (Settings 2) X PIXEL MAPPING
This function has already been adjusted
at factory shipping, and no adjustment is
needed right after purchase. Approximately
once a year is recommended.
For best results, wait at least one minute
after taking or viewing pictures before
performing pixel mapping. If the camera is
turned off during pixel mapping, be sure to
perform it again.
To adjust the CCD and the image
processing function
Press the H button when [START]
(Submenu 2) is displayed.
The camera checks and adjusts the CCD and the
image processing function at the same time.
●
Adjusting the brightness of the monitor
[s]
s (Settings 2) X s
Submenu 2 Application
BRIGHT/
NORMAL
Selects the monitor brightness
depending on the surrounding
brightness.
Setting the date and time [X]
s (Settings 2) X X
“Setting the date, time and time zone”
(p. 12)
To select the date display order
1 Press I after setting Minute, and use
FG to select the date display order.
02 26 12 30:..2010
OK
SET
X
Y M D TIME
MENU
CANCEL
Y/M/DY/M/D
Date order

Olympus FE-4020 Specifications

General

Megapixel	14 MP
Camera type	Bridge camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Maximum image resolution	4288 x 3216 pixels
Still image resolution(s)	3264 x 2448\\r 2560 x 1920\\r 2048 x 1536\\r 1600 x 1200\\r 1280 x 960\\r 640 x 480\\r 1920 x 1080
Optical zoom	4 x
Focal length range	26 - 105 mm
Maximum aperture number	5.9
Minimum aperture number	2.6
Maximum focal length (35mm film equiv)	105 mm
Minimum focal length (35mm film equiv)	26 mm
Normal focusing range	0.6 – infinity m
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Super Macro focusing range	0.04 – infinity m
Macro focusing range (tele)	0.6 - ∞ m
Macro focusing range (wide)	0.2 - ∞ m
Normal focusing range (tele)	1 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
Light exposure modes	-
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	4 s
Flash modes	Auto, Fill-in, Red-eye reduction
Flash range (tele)	0 - 2.11 m
Flash range (wide)	0 - 4.79 m
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
HD type	Not supported
Video formats supported	AVI
Maximum video resolution	- pixels
Memory slots	1
Internal memory	18 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	8 GB
Display diagonal	2.7 \
Viewfinder type	Not available
HDMI	No
USB version	2.0
Scene modes	Candlelight, Cuisine, Documents, Fireworks, Night, Night portrait, Party (indoor), Pet, Portrait, Self-portrait, Sports, Sunset, Landscape (scenery)
White balance	Auto, Daylight, Fluorescent, Tungsten
Shooting modes	Auto, Movie, Scene
Self-timer delay	2, 12 s
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery life (CIPA standard)	180 shots
Product color	Pink
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	22.8 mm
Width	95 mm
Height	56.2 mm
Weight	128 g
