EN 10
EN
(*1) During Underwater Wide-Angle 1 or Underwater Macro shooting mode, the OK button
functions as the AF LOCK button.
(*2) The Wi-Fi button functions only for TG-860.
*
*
*
*
h ( (Movie) button
i Mode dial knob
j q (Play) button
k INFO button/arrow pad S
*
*
*
l # button/Arrow pad X
m OK button (*1)
n jY button/ button/
arrow pad T
*
*
o MENU/Wi-Fi
button (*2)
p Arrow pad W
q Monitor window
Memo:
The Case operation parts marked by * correspond to the operation parts of
the digital camera. When the operation parts of the Case are operated, the
corresponding functions of the digital camera will operate. For details of the
functions, refer to the instruction manual for the digital camera.
PT-057_EN.book Page 10 Friday, November 21, 2014 10:13 AM
