EN 12
EN
Installation and removal of the monitor hood
Installation
Fit the monitor hood as shown in the figure into the guides above and
below the monitor window one after the other.
Removal
Remove the monitor hood from the guides above and below the monitor
window one after the other by widening the monitor hood.
Mounting and removing the lens cap
Fit the lens cap onto the lens ring as
shown in the figure. Be sure to
remove the lens cap before
shooting.
Guides
Installation Removal
PT-057_EN.book Page 12 Friday, November 21, 2014 10:13 AM
