Names of Parts
1 Self-timer lamp/
AF illuminator .......................... p.24, 37
2 Flash ............................................. p.22
3 Microphone ................................... p.53
4 Lens
5 Battery compartment cover ........... p.10
6 Battery compartment lock ............. p.10
7 Tripod socket
8 Speaker
9 Diopter adjustment dial ................. p.25
Camera unit
1
5
6
7
8
2
4
9
12
10
11
13
3
10
#
button (fl ash fl ip-up) ................. p.22
11 DC-IN jack .................................... p.78
12 Connector cover ............... p.61, 64, 70
13 Multi-connector ................. p.61, 64, 70
