3-13
momentarily. The location is now empty and will not appear with any of the saved presets
when trying to recall a preset.
The preset number just erased will still appear on the LCD until moved from that
preset number. Once moved to a different preset, it will no longer appear when
trying to recall a preset.
Invalid Measurement Indications
The LCD display indicates when a measurement or statistic is invalid, as shown in Figure 10
below.
I
NDICATION DESCRIPTION
O rnG
The current measurement or statistic is over-range for the selected
thermocouple type. Also, Instrument is in mV mode, “old” is off
and “Source” is off. Those settings can lead to an Over range
The current measurement or statistic is under-range for the
selected thermocouple type
OPEn No probe is connected or the probe sensor is faulty
————— Cannot compute a valid statistical result
Short ChAn1
A thermocouple, shorted transducer, or other short circuit is
plugged into the Source Channel during startup.
Figure 10: Invalid Measurement Indications
