Omron 1S Series User Manual

26AC Servomotors/Servo Drives 1S-series Instruction Manual
• This is a product designed for industrial environments.
Use in residential area may cause radio interference, in which case the user may be required
to take adequate measures to reduce interference.
• This type of PDS is not intended to be used on a low-voltage public network which supplies
domestic premises.
 Manufacturer and EU Representative
 Compatibility Conditions of Low Voltage Directive
 Installation Environment
 Servo Drive Rating
 200-VAC Input Model: R88D-1SANH-ECT
Compatibility Conditions of EU Directives
Manufacturer: OMRON Corporation (Manufacturer)
Shiokoji Horikawa, Shimogyo-ku, Kyoto, 600-8530, Japan
EU Representative: OMRON Europe B.V. (Representative and Importer in EU)
Wegalaan 67-69, 2132 JD Hoofddorp, The Netherlands
Item Specifications
Operating ambient temperature and humidity 0 to 55°C, 90% max. (with no condensation)
Overvoltage category III
Pollution Degree 2
Altitude 1,000 m max.
Protective structure IP20 (To be built into the IP54 enclosure)
Protection class I
Input power supply
AC power supply
When the DC power input is used, the Servo
Drive does not conform to EU standards.
Short-circuit current rating (SCCR) 5,000 Arms
Item Unit
Model (R88D-1SAN)
02H-ECT 04H-ECT 08H-ECT
Rated voltage VAC
200 to 240
Single-phase/3-phase
Power supply frequency Hz 50/60
Rated input
current
Single-phase Arms 2.7 4.6 7.3
3-phase Arms 1.5 2.7 4.0
Rated output W 200 400 750
Item Unit
Model (R88D-1SAN)
10H-ECT 15H-ECT 20H-ECT 30H-ECT
Rated voltage VAC
200 to 240
3-phase
Single-
phase/
3-phase
3-phase
