Omron 1S Series User Manual

40AC Servomotors/Servo Drives 1S-series Instruction Manual
• Observe the following precaution if you use this product in Korea.
 Guide for Users
This equipment has been evaluated for conformity in a commercial environment.
When used in a residential environment, it may cause radio interference.
• The 1S-series Servo Drives comply with the Korean Radio Regulations (KC).
• The 1S-series Servomotors are exempt from the Korean Radio Regulations (KC).
 Combination Tables
The tables in this section show the possible combinations of 1S-series Servo Drives and Ser-
vomotors. The Servomotors and Servo Drives can only be used in the listed combinations. “”
at the end of the motor model number is for options, such as the shaft type and brake.
 3,000-r/min Servomotors and Servo Drives
 1,500-r/min Servomotors and Servo Drives
Korean Radio Regulations (KC)
Combinations of Servo Drives and Servomotors
Main circuit power
supply voltage
Rated output
Servomotor
Servo Drive
Single-phase/3-phase
200 VAC
200 W R88M-1AM20030T- R88D-1SAN02H-ECT
400 W R88M-1AM40030T- R88D-1SAN04H-ECT
750 W R88M-1AM75030T- R88D-1SAN08H-ECT
1.5 kW R88M-1AL1K530T- R88D-1SAN15H-ECT
3-phase 200 VAC 1 kW R88M-1AL1K030T- R88D-1SAN10H-ECT
2 kW R88M-1AL2K030T- R88D-1SAN20H-ECT
2.6 kW R88M-1AL2K630T- R88D-1SAN30H-ECT
3-phase 400 VAC 750 W R88M-1AL75030C- R88D-1SAN10F-ECT
1 kW R88M-1AL1K030C- R88D-1SAN10F-ECT
1.5 kW R88M-1AL1K530C- R88D-1SAN15F-ECT
2 kW R88M-1AL2K030C- R88D-1SAN20F-ECT
3 kW R88M-1AL3K030C- R88D-1SAN30F-ECT
Main circuit power
supply voltage
Rated output
Servomotor
Servo Drive
Single-phase/3-phase
200 VAC
1.5 kW R88M-1AM1K515T- R88D-1SAN15H-ECT
3-phase 200 VAC 2.7 kW R88M-1AM2K715T- R88D-1SAN30H-ECT
3-phase 400 VAC 1.5 kW R88M-1AM1K515C- R88D-1SAN15F-ECT
3 kW R88M-1AM3K015C- R88D-1SAN30F-ECT
