Operation List Arranged by Purpose Section 1-6
16
1-6 Operation List Arranged by Purpose
The following lists show the operation for each purpose.
1-6-1 Setting Operation Environment
Purpose Menu or Button to select
Connect the CX-Simulator Debug Console | File Menu | Work CX-Simulator |Connect Simu-
lator
Disconnect the CX-Simulator Debug Console | File Menu |Work CX-Simulator | Disconnect
Simulator
Create a new PLC Select System Status | Setting | Select PLC | Create a new PLC
Open existing PLC Select System Status | Setting | Select PLC | Open existing PLC
Add a PLC unit System Status | Setting | PLC unit Setting
Change UM System Status | Setting | UM Setting
Initialize PLC memory System Status | Initialize PLC
1-6-2 Program Execution
Objective Menu or Button to select
Execute continuously Debug Console | Continuous Run button
Execute a single scan Debug Console | Scan Run button
Scan continuously Debug Console | Continuous Scan Run button
Execute a single step Debug Console | Step Run button
Execute steps continuously Debug Console | Continuous Step Run button
Pause the program execution Debug Console | Pause button
Stop the program Debug Console | Stop button
Repeat scan from the beginning Debug Console | Scan Replay button
Reset Debug Console | Reset button
1-6-3 Program Debugging
Objective Menu or Button to select
Set for Step Run Debug Console | Step Run
Set break points In the above operation, right-click the program address to set a
breakpoint to and set Select BreakPoint when the pop-up menu is
displayed.
Clear the break point In the above operation, right-click the program address to clear a
breakpoint for and select Clear BreakPoint when the pop-up menu
is displayed.
Clear all break points In the above operation, right-click the Step Run window and select
Clear All BreakPoints when the pop-up menu is displayed.
Designate a start point In the above operation, right-click the program address to set a
start point to and set Select Start Point when the pop-up menu is
displayed.
Clear a start point In the above operation, right-click the program address to clear a
start point for and select Clear Start Point when the pop-up menu
is displayed.
Stop the program when the con-
tent of I/O memory area meets
certain conditions
Debug Console | I/O Break conditions Setting
