Manufacturer Model Description
Cisco Systems,
Inc.
Consult the manufacturer.
http://www.cisco.com/
Contec USA,
Inc.
Consult the manufacturer
.
http://www.contec.com/
Phoenix Contact
USA
Consult the manufacturer
.
https://www.phoenixcontact.com
Twisted-pair Cables and Connectors
Applicable EtherNet/IP communications cables and connectors vary depending on the used baud rate.
For 100Base-TX and 10Base-T, use an STP (shielded twisted-pair) cable of category 5 or higher. Y
ou
can use either straight or cross cable.
For 1000Base-T, use an STP (shielded twisted-pair) cable (double shielding with aluminum tape and
braiding) of category 5e or higher. You can use either straight or cross cable.
Cabling materials used for EtherNet/IP communication cables are shown in the table below.
"100Base-TX" in the "Product" column of the table below indicates that either 100Base-TX or 10Base-
T can be used.
Product Manufacturer Model
For 1000Base-T
and 100Base-TX
Size and con-
ductor pairs:
AWG 24 × 4
pairs
*1
Cable Hitachi Metals, Ltd. NETST
AR-C5E
SAB 0.5 × 4P CP
Kuramo Electric Co. KETH-SB
JMACS Japan Co., Ltd. IETP-SB
RJ45 Connec-
tors
Panduit Corporation MPS588
For 100Base-TX Size and con-
ductor pairs:
A
WG22 × 2P
*1
Cable Kuramo Electric Co., Ltd.
KETH-PSB-OMR
JMACS Japan Co., Ltd. PNET/B
RJ45 Assembly
Connectors
OMRON XS6G-T421-1
*1. We recommend that you use cables and connectors in above combinations.
Attaching the Connectors to the Cable and Pin Assignments
Use straight wiring to attach the connectors to the communications cable, as shown below.
4 Mounting and Wiring
4-18
CK3E-series Programmable Multi-Axis Controller User’s Manual Hardware (I610)
