Omron CPM1A User Manual

31
2-2 Unit Components
2-2-1 CPU Unit Components
CPU Units with 10 I/O Terminals
CPM1A-10CDR--V1/10CDT--V1/10CDT1--V1
1. Power supply input terminals
3. Protective earth terminal
5. Input terminals
10. Analog controls
11. Peripheral Port
7. PC status indicators
8. Input indicators
9. Output indicators
4. Power supply output terminals
(AC power supplies only)
6. Output terminals
CPM1A-10CDR-/10CDT-/10CDT1-
1. Power supply input terminals
2. Functional earth terminal
(AC power supplies only)
3. Protective earth terminal
5. Input terminals
10. Analog controls
11. Peripheral Port
7. PC status indicators
8. Input indicators
9. Output indicators
4. Power supply output terminals
(AC power supplies only)
6. Output terminals
Unit Components
Section 2-2
