D4N
Recommended Connectors
Use connectors with screws not exceeding 9 mm, otherwise the
screws will protrude into the case interior, interfering with other
components in the case.
The connectors listed in the following table have connectors with
thread sections not exceeding 9 mm.
Use the recommended connectors to ensure conformance to IP67.
Use LAPP connectors together with seal packing (JPK-16, GP-13.5,
or GPM20), and tighten to the specified tightening torque. Seal
packing is sold separately.
x LAPP is a German manufacturer.
x Before using a 2-conduit 1/2-14NPT type, attach the provided
changing adaptor to the Switch and then connect the
recommended connector.
Others
x When attaching a cover, be sure that the seal rubber is in place and
that there is no foreign material present. If the cover is attached
with the seal rubber out of place or if foreign material is stuck to the
rubber, a proper seal will not be obtained.
x Do not use any screws to connect the cover other than the
specified ones. The seal characteristics may be reduced.
x Make sure that foreign particles do not enter the head when
removing the screws from the four corners to change the head
position in any of the four directions.
x Use the following recommended countermeasures to prevent
telegraphing when using adjustable or long levers.
1. Make the rear edge of the dog smooth with an angle of 15q to
30qor make it in the shape of a quadratic curve.
2. Design the circuit so that no error signal will be generated.
Size Manufacturer Model
Applicable cable
diameter
G1/2 LAPP
ST-PF1/2
5380-1002
6.0 to 12.0 mm
Pg13.5 LAPP
ST-13.5
5301-5030
6.0 to 12.0 mm
M20 LAPP
ST-M20 u 1.5
5311-1020
7.0 to 13.0 mm
1/2-14NPT LAPP
ST-NPT1/2
5301-6030
6.0 to 12.0 mm
http://www.ia.omron.com/
20
(c)Copyright OMRON Corporation 2007 All Rights Reserved.
