Appendix A
Specifications
Ratings
Note (1) For the setting ranges for each sensor input, see page 172.
(2) When connecting the ES2, connect it 1:1.
Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC, 50/60 Hz/24 VDC
Operating voltage range 85 to 110% of rated supply voltage
Power consump-
tion
E5CZ 7.5 VA 5.5 VA/3.5W
E5CZ-U 6 VA 4.5VA/2.5W
E5AZ 8.5 VA 6 VA/4 W
E5EZ 8.5 VA 6 VA/4 W
Sensor input (See note 1.) Temperature input type
Thermocouple: K, J, T, E, L, U, N, R, S, B
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Voltage input: 0 to 50 mV
Controllers with Analog Inputs
Current input: 4 to 20 mA, 0 to 20 mA (Input impedance: 150 Ω max.)
Voltage input: 1 to 5 V, 0 to 5 V, 0 to 10 V (Input impedance: 1 MΩ max.) (See note 2.)
Control output Relay output E5CZ Relay output:
SPST-NO, 250 VAC, 3 A (resistive load), electrical dura-
bility: 100,000 operations
Min. applicable load: 5 V, 10 mA
E5CZ-U SPDT, 250 VAC, 3A (resistive load), electrical durability:
100,000 operations
Min. applicable load 5 V 10 mA
E5AZ
E5EZ
Relay output:
SPST-NO, 250 VAC, 5 A (resistive load), electrical dura-
bility: 100,000 operations
Min. applicable load: 5 V, 10 mA
Voltage output E5CZ
E5CZ-U
Output voltage 12 VDC ±15% (PNP), max. load current
21 mA, with short-circuit protection circuit
E5AZ
E5EZ
Output voltage 12 VDC +15%/−20% (PNP), max. load cur-
rent 40 mA, with short-circuit protection circuit
Current output 4 to 20 mA DC, 0 to 20 mA DC, Load: 600 Ω max., Resolution: approx.
2,700
Alarm output E5CZ
E5CZ-U
SPST-NO, 250 VAC, 1 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
E5AZ
E5EZ
SPST-NO, 250 VAC, 2 A (resistive load), electrical durability: 100,000
operations
Min. applicable load: 5 V, 10 mA
Control method 2-PID or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 11-segment/7-segment digital display and single-lighting indicator
Other functions Depend on the model
Ambient temperature −10 to 55°C (with no condensation or icing)
Ambient humidity 25% to 85%
Storage temperature −25 to 65°C (with no condensation or icing)
Altitude 2,000 m or less
Recommended fuse T2A, 250 VAC, time lag, low shut-off capacity
Installation environment Installation Category II, Pollution Class 2 (IEC 61010-1 compliant)
