219
Motor Timer H2A
Miniature, High-performance Motor
Timer
Employs high-reliability bifurcated contacts for
output.
Moving pointer provided inall types forconfirmation
of elapsed time.
Employs time-out and power ON indicators for all
types.
Wide variety of timing ranges from 5 s to 24 hrs.
RC
Ordering Information
Operation/resetting system Internal connection Time-limit
t
t
Instantaneous
t
t
Mounting
p
/
g
y
contact contact
Surface mounting
(see note 2)
Time-limit operation/
l
f
t
t
i
Parallel motor and
l
t
h
t
i
SPDT --- H2A
p
/
self-resetting clutch connection
SPST-NO H2A-H
Note: 1. Specify both the model number and supply voltage when ordering.
2. Surface mounting models can be used as a flush mounting type by attaching an exclusive adapter (Y92F-40) to the timer.
Specifications
Time Ranges
Rated time Time setting range Time division
50 Hz 60 Hz
5s 0.2to6s 0.2to5s 0.2 s
10 s 0.5to12s 0.5to10s 0.5 s
30 s 1to36s 1to30s 1.0 s
60 s 2to72s 2to60s 2.0 s
3min 1/6to31/2min 1/6to3min 10.0 s
6min 1/4to71/6min 1/4to6min 15.0 s
12 min 1/2to14min 1/2to12min 30.0 s
30 min 1to36min 1to30min 1.0 min
60 min 2to72min 2to60min 2.0 min
3hrs 1/6to31/2hrs 1/6to3hrs 10.0 min
6hrs 1/4to7hrs 1/4to6hrs 15.0 min
12 hrs 1/2to14hrs 1/2to12hrs 30.0 min
24 hrs 1to28hrs 1to24hrs 1.0 hrs
