Omron H3CR-A User Manual

308
-
Solid-state Timer H3BF
DIN-sized (48 x 48 mm) Twin Timer
Sixteen selectable time rages (0.05 s to 100 hrs).
Easy-to-read large scale and easy-to-set coaxial
dual knob facilitate time setting.
Equipped with ON and OFF operation indicators for
control output.
RC
Ordering Information
Operation/ resetting
t
Terminal Time-limit contact Model
p
/
g
system
Surface/
Track mounting
Flush mounting
Time-limit operation/
time-limit resetting/
self resetting
8-pin round socket DPDT H3BF-8 (with P2CF-08
socket)
H3BF-8 (with Y92F-30
adapter)
Note: Specify both the model number and supply voltage when ordering.
Accessories (Order Separately)
Same as H3BA except for the following exception.
Timer
Track mounted socket
(
t
1
)
Back connecting socket
(see note 1)
Solder terminal Screw terminal
H3BF-8 P2CF-08 PL08 P3G-08
Note: Track mounted socket can be used as a front connecting socket.
Replacements
H3BF Replacement model Reference page
H3BF-8 H3CR-F8 37
H3CR-F8-300
Specifications
Time Ranges
Time unit s min hrs 10 h
Setting 0.5 0.05 to 0.5 0.5to5h
1 0.1to1 1to10h
5 0.5to5 5to50h
10 1to10 10 to 100 h
