Solid-state Timer H3BA
DIN-sized (48 x 48, 45 x 75 mm) Timer
with 3 Selectors to Cover 64
Specifications
Sixteen selectable time ranges (0.05 s to 100 hrs).
Four operation modes switch-selectable.
External signal inputs for easy control of the timer
from a remote site.
A single LED indicator for both timing (RUN) and
time-up (UP).
RC+
Ordering Information
Operation/ resetting
system
Operation mode
Terminal Time-limit
contact
Instantaneous
contact
Model
s
y
s
t
e
Surface/
track mounting
Flush mounting
Time-limit operation/
self-resetting/external
resetting(seenote2)
ON-delay,
Repeat cycle,
Signal ON-/OFF-delay,
o
r
S
i
g
n
a
l
O
F
F
-
d
e
l
a
y
11-pin round
socket
DPDT --- H3BA (with
P2CF-11 socket)
H3BA (with
Y92F-30 adapter)
or
S
i
gna
l
O
F
F
-
d
e
l
ay
operation (selectable)
Front screw SPDT --- H3BA-FA ---
Time-limit operation/
self-resetting
ON-delay operation 8-pin round
socket
SPDT SPDT H3BA-8H (with
P2CF-08 socket)
H3BA-8H (with
Y92F-30 adapter)
DPDT --- H3BA-8 (with
P2CF-08 socket)
H3BA-8 (with
Y92F-30 adapter)
Note: 1. Specify both the model number and supply voltage when ordering.
2. The operation/resetting system isdependent on the selected operation mode.For details, see
“Timing charts (Operation Modes)”
.
Accessories (Order Separately)
Timer
Track mounted socket
(
1
)
Back connecting socket
(see note 1)
Solder terminal Screw terminal
H3BA P2CF-11 PL11 P3GA-11
H3BA-8H/H3BA-8 P2CF-08 PL08 P3G-08
Note: Track mounted socket can be used as a front connecting socket.
Top View Bottom View
Replacements
H3BA Replacement model Reference page
H3BA H3CR-A 16
H3BA-8 H3CR-A8
H3BA-8H H3CR-A8E(L)
H3BA-FA H3DR-A 66
