8-pin, finger safe type
P3G-08 with Y92A-48G (see note 1)
11-pin P3GA-11
1
1-pin, finger safe type
P3GA-1
1 with Y92A-48G (see note 1)
Hold-down Clip (see note 2)
For PL08 and PL1
1 Sockets
Y92H-7
For PF085A Socket
Y92H-8
Note: 1.
Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 or P3GA-1
1 Socket.
2.
Hold-down Clips are sold in sets of two.
Specifications
General
Item H3CR-F H3CR-F8 H3CR-FN H3CR-F8N
Operating
mode
Flicker OFF start Flicker ON start
Pin type
11-pin 8-pin 11-pin 8-pin
Operating/Reset method
T
ime-limit operation/T
ime-limit reset or self-reset
Output type
Relay output (DPDT)
Mounting method
DIN track mounting, surface mounting, and flush mounting
Approved standards
UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 (VDE0435/P2021), IEC60664-1 (VDE0110) 4kV/2,
and EN60947-5-1 (for contact output).
Time Ranges
0.05
s to 30 h Models
T
ime unit
s (sec)
x10 s (10 s)
min h (hrs)
Setting 1.2
0.05 to 1.2 1.2 to 12 0.12 to 1.2
3
0.3 to 3 3 to 30 0.3 to 3
12
1.2 to 12 12 to 120 1.2 to 12
30
3 to 30 30 to 300 3 to 30
Note:
Instantaneous output is available at any time range. T
o obtain instantaneous output, set to below 0.
1.2 s to 300 h Models
T
ime unit
x10 s (10 s)
x10 min (10 min)
h (hrs)
x10 h (10 h)
Setting 1.2
1.2 to 12 1.2 to 12 0.12 to 1.2 1.2 to 12
3
3 to 30 3 to 30 0.3 to 3 3 to 30
12
12 to 120 12 to 120 1.2 to 12 12 to 120
30
30 to 300 30 to 300 3 to 30 30 to 300
Note:
Instantaneous output is available at any time range. T
o obtain instantaneous output, set to below 0.
To Next Page
