Solid-state Timer H3CR (Common) 47
Accessories (Order Separately) (Common)
Note: The undermentioned is common for all H3CR models.
Note: All units are in millimeters unless otherwise indicated.
Flush Mounting Adaptor
45
+0.6
−0
(N)
45
+0.6
−0
58 52
42
48
Y92F-30
Panel Cutout
0.5 R max.
Panel
Note: The adapters for two or more timers mounted in a vertical line are different in
orientation from those mounted in a horizontal line.
N can be obtained as follows (n: the number of H3CR models arranged side by side)
Without a Cover: N = (48n - 2.5)
+1
/-0
With the Protective Cover: N = (51n - 5.5)
+1
/-0
With the Panel Cover: N = (50n - 4.5)
+1
/-0
P3G
Back Connecting Socket
88
58
45±0.15
43±0.2
58
45±0.2
50
+0.2
-0
56
68
76±0.2
45
+0.5
−0
55
+0.5
−0
45±0.15
52.3 (63.7)
52.3 (63.7)
Y92F-70/-73
Y92F-71/-74
Panel
Panel
Panel Cutout
Adapter mounting hole Two, 4.5 dia.
52 to 53
65 to 66
R0.5 max.
R0.5 max.
Note: The mounting panel thickness
should be 1 to 3.2 mm.
Note: The mounting panel thickness
should be 1 to 3.2 mm.
P3G
Back Connecting Socket
P3G
Back Connecting Socket
Note: The value shown in
parentheses is for
the Y92F-70.
(See note.)
Note: The value shown in
parentheses is for
the Y92F-71.
(See note.)
