2 Multifunction Digital Timer H5CX-A/-L
Multifunction Digital Timer
H5CX-A/-L
DIN 48 ´ 48-mm Multifunction Digital Timer
with a Bright, Easy-to-view, Negative
Transmissive LCD.
• Programmable PV color to visually alert when output status
changes (screw terminal block models).
• Intuitive setting enabled using DIP switch (H5CX-A/-A11 mod-
els) and ergonomic up/down digit keys.
• Twin timer in one body to meet a broader range of cyclic control
application requirements as well as ON/OFF duty adjustable
flicker mode.
• PNP/NPN switchable DC-voltage input (H5CX-A/-A11 models).
• Meet a variety of mounting requirements:
Screw terminal block models, and pin-style terminal models.
• Six-language instruction manual.
Contents
Model Number Structure.................................................................3
Ordering Information .......................................................................3
Specifications..................................................................................4
Connections ....................................................................................7
Nomenclature..................................................................................11
Dimensions .....................................................................................12
Operating Procedures .....................................................................17
Setting Procedure Guide ..........................................................17
Operating Procedures (Timer Function) ...................................18
Operating Procedures (Twin Timer Function) ...........................26
Operation in Timer/Twin Timer Selection Mode........................31
Additional Information .....................................................................32
