Omron LD Series User Manual

2
LD Series
Components and Functions
LD-60, LD-90
Components and Functions
LD-250
*ESD Model Shown
AUX Power & I/O
Internal connections
to power and control
custom topper models.
Operation Panel
Access to system power,
E-Stop, and the operation
status display.
Low Front Laser
Obstacle sensor detects
low-profile objects when
moving forward.
Light Discs
Status indicator is
located on both sides.
Front Bumper
Stops when in contact
with an obstacle.
Safety Scanning Laser
Safety-rated laser used for SLAM
(Simultaneous Localization and Mapping)
and safety functionality.
Rear Sonar
Detects rear
obstacles using sonar.
Performance Battery
Up to 15 hours of runtime between
charges for up to 7 years.
Charge Dock
Integrated contacts for
automated charging.
Hardened Construction
Metal chassis and skins for
increased duty and durability.
Low Front Laser
Obstacle sensor detects low-profile
objects when moving forward.
Safety Scanning Laser
Safety-rated laser used for SLAM
(Simultaneous Localization and
Mapping) and safety functionality.
E-Stop Buttons
E-stop located on both
sides and top.
Light Discs
Status indicator is located
on both sides.
Rear ToF Sensors
Detects rear obstacles
using infrared light.
Aux Power & I/O
Internal connections to
power and control custom
topper modules.
Performance Battery
Up to 13 hours of runtime
between charges for up to 7 years.
Charge Dock
Integrated contacts for
automated charging.
Operation Panel
Access to system power, E-Stop,
and the operation status display.
