Omron MC-510 Gentle Temp User Manual

If you want to measure continuously:
• About 10 seconds after you
remove the unit from the ear,
a "°C" mark flashes.
• Return to Step 3: Insert the
probe into the ear.
To end the measurement:
• In approximately 1 minute, the
unit will be turned off
automatically. It cannot be
turned off manually.
Memory Feature:
• The last measurement value is
stored automatically. It can be
recalled when the unit is
turned on. The value will be
displayed with ‘M’ symbol.
Caution:
If main unit warms up after continuous measurement, allow
the unit to turn off automatically to avoid incorrect reading.
Then switch on again to continue measurement.
TITLE
10
AFTER THE MEASUREMENT IS FINISHED
After
approximately
10 seconds
M
Asia EN-02-20[MC-510]-9 10/1/03 11:59 AM Page 10

Omron MC-510 Gentle Temp Specifications

Power

voltage	3 VDC
power consumption	0.05 W
battery life	Measurements of approx. 2000 times

Temperature Measurement

temperature indication	In 3 digits in +°C or 4 digits in +°F
precision	±0.3°C (±0.5°F) or ±0.2°C (±0.4°F)
measurement range	34 to 42.2°C (93.2 to 108°F)

Operating Environment

operating temperature	10 to 40°C (50 to 104°F)
operating relative humidity	30 to 85%
storage temperature	-20 to 60°C (-4 to 140°F)
storage relative humidity	10 to 95%

Weight and Dimensions

weight	Approx. 50g
external dimensions	Approx. 45 (W) x 94 (H) x 58 (D)
