Omron MC-510 Gentle Temp User Manual

TITLE
8
2
Press the Switch.
TO CHANGE °C/°F MEASUREMENT MODE
The thermometer default is set to Centigrade ˚C.
To change the unit of temperature from ˚C (Centigrade) to ˚F (Fahrenheit)
to follow the procedure shown below. From the off position (blank display):
1) Press and hold the Switch for "approx. 3 seconds." ˚C flashes on the LCD.
2) Remove your finger from the Switch.
3) Each time the Switch is pressed, ˚F and ˚C are displayed alternatively.
(5 seconds after pressing, the thermometer turns off automatically)
4) From the off position (Blank display) hold the thermometer switch for 5
seconds while ˚F is displayed.
5) The thermometer is set for ˚F mode. To select ˚C mode, start from Step 1.
The power is turned on. After the display
check is completed, "°C" flashes.
PREPARATION BEFORE MEASUREMENT
M
M
The " " mark
displayed at this
time is for display
check only.
The backlit screen
will be illuminated
for 2 seconds
when the switch
is pressed.
Asia EN-02-20[MC-510]-9 10/1/03 11:59 AM Page 8

Omron MC-510 Gentle Temp Specifications

Power

voltage	3 VDC
power consumption	0.05 W
battery life	Measurements of approx. 2000 times

Temperature Measurement

temperature indication	In 3 digits in +°C or 4 digits in +°F
precision	±0.3°C (±0.5°F) or ±0.2°C (±0.4°F)
measurement range	34 to 42.2°C (93.2 to 108°F)

Operating Environment

operating temperature	10 to 40°C (50 to 104°F)
operating relative humidity	30 to 85%
storage temperature	-20 to 60°C (-4 to 140°F)
storage relative humidity	10 to 95%

Weight and Dimensions

weight	Approx. 50g
external dimensions	Approx. 45 (W) x 94 (H) x 58 (D)
