Omron POWLI User Manual

79
A. Specications
Frequency 50/60Hz ± 4Hz
Maximum current 5.8A 16A
Phase Single-phase, two-wire
Input plug shape Schuko CEE 7/7P Schuko CEE 7/7P
Input protection Reset-type overcurrent protection device
Input protection capacity 10A 20A
Output Allowable connection capacity *1 1000VA/700W 3000VA/2100W
Voltage (effective value) *2
Peak voltage value 220V mode: AC310V ± 6%
(In Commercial Power Mode) 230V mode: AC324V ± 6% 240V mode: AC338V ± 6%
Peak voltage value 220V mode: AC310V+6%/-10%
(In Battery Mode) 230V mode: AC324V+6%/-10% 240V mode: AC338V+6%/-12%
Frequency 50/60Hz ± 1Hz
Phase Single-phase, two-wire
Output waveform Sine wave
Waveform distortion rate 220V mode: 10% max.
(Rectified load, at rated output) 230V mode: 10% max. 240V mode: 12% max.
Number of output receptacles IEC60320 C13: 3 pcs.
IEC60320 C19: 1 pcs. C13 : 5 pcs.
Terminal block: 2 lines Terminal block: 2 lines
Power failure switching time Uninterrupted
Commercial direct shipment (switching time) 4msec. max.
Backup time *3 Minimum 5 minutes
Battery Type Compact sealed lead battery
Sealed lead battery life expectancy
4 to 5 years (long operating life) *At ambient temperature of 20˚C
Battery capacity (V/Ah) (x Quantity)
12V DC/ 7.2 Ah (x 3) 12V DC/ 8 Ah (x 6)
Charging time 8 hours *4
Environment Operating ambient temperature 0 to 40˚C (during operation)/ -15 to 50˚C (during storage)
Operating ambient humidity 25 to 85%RH (during use)/10 to 90%RH (during storage)
Dimensions
(W×H×Dmm) 145 x 395 x 224 (±1) mm *5 213 x 537 x 432 (±1) mm *6
Weight of unit
Approx. 15.5 kg Approx. 35 kg
Internal power consumption (max.) 50W (100W max.) 55W (155W max.) *7
Noise regulation (compliance standard) VCCI Class A
Safety standards / RoHS directive compliance CE / RoHS compliance
Noise 50 dB max. 55 dB max.
Serial communication (RS-232C)(Interface) D-Sub 9pin
Serial communication (USB)(Interface) B type*8
Contact signal (Interface) D-Sub 9pin*9
BU1002SWG BU3002SWG Type
220V mode AC220V ± 3%
230V mode AC230V ± 3%
240V mode AC240V ± 3%
Method Operation method Full-time inverter supply method
Connectable devices PC, display, and peripherals
Input Rated input voltage 220/230/240 VAC
Input voltage range
AC185±4 to 276±4V (with 85% or less connection load)
AC210±4 to 276±4V (with 85% or more connection load)
*1: Make sure that both the VA value and the W value of the load capacity connected to the UPS are within the range specied here.
*2: Check the operation beforehand if the unit is used in any mode other than “220V AC mode”. In some cases, the maximum voltage
of output in Battery Mode may be lower than the maximum voltage in usual operation (commercial power supply).
*3: The backup times shown here are for when rated load is connected, at 20
°
C, and for initial characteristics.
*4: When an additional battery unit is connected, the charging time is 24 hours.
*5: The height includes the 13mm height of the rubber feet.
*6: The height includes the 56mm height of the casters.
*7: 170W max when and additional battery unit is connected.
*8: USB or RS-232C either is available. (unusable at the same time)
*9: This UPS is equipped with SC07 (NPN signal output card) at the time of factory shipment. To use the PNP connection, replace the
SC07 with the SC08G included in the package.
