Onkyo BD-SP809 Service Manual

1-1-1 E5WB0SP
SPECIFICATIONS
General
Signal system NTSC Color
Power requirements
AC120 V, 60 Hz
Power consumption 22 W (standby: 0.5 W)
Dimensions (width x height x depth) 17-1/8 x 4-1/8 x 12-5/16 inches (435 x 104 x 313 mm)
Weight 10.4 lbs (4.7 kg)
Operating temperature 41 F°(5 °C) to 104 F°(40 °C)
Operating humidity Less than 80 % (no condensation)
Audio
BD Linear Audio 4 Hz–88 kHz (192 kHz)
DVD Linear Audio
4 Hz–44 kHz (96 kHz), 4 Hz–22 kHz (48 kHz)
Audio CD 4 Hz–20 kHz (44.1 kHz)
Signal to Noise Ratio 100 dB
Audio Dynamic Range 98 dB
THD (Total Harmonic Distortion) 0.005 % (1 kHz)
Terminals
USB input
TYPE A
USB 2.0
Bus power current: MAX. 500 mA
Audio output (Analog)
RCA jack x 2
L/R: 2 Vrms (output impedance: more than 1 kƙ)
Video output
RCA jack x 1 1Vp-p (75ƙ)
Component video output
RCA jack x 3
Y: 1 Vp-p (75 ƙ)
PB: 700 mVp-p (75 ƙ)
PR: 700 mVp-p (75 ƙ)
Audio output (Digital)
RCA jack x 1
Optical jack x 1
500 mVp-p (75 ƙ)
Digital connector
HDMI output
HDMI jack x 2 Video: 480i, 480p, 720p, 1080i, 1080p, 1080p24 / Audio
ETHERNET terminal 10BASE-T/100BASE-TX
D Note
• The specifications and design of this product are subject to change without notice.
E5WB0UDENBook.indb56 2011/06/0211:48:23

Onkyo BD-SP809 Specifications

General

3D	Yes
Depth	313 mm
Wi-Fi	No
Width	435 mm
Height	104 mm
Weight	4700 g
Display	-
Device type	Blu-Ray player
Package depth	411 mm
Package width	551 mm
Product color	Silver
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS-HD
Package height	217 mm
Package weight	6100 g
Cables included	AV
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Dimensions (WxDxH)	- mm
Disc types supported	BD-R, BD-RE, BD-ROM, CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW
Dynamic range (1kHz)	98 dB
USB 2.0 ports quantity	1
Audio formats supported	MP3, WMA
Image formats supported	JPG
Video formats supported	AVCHD, DIVX, MKV, MPEG1, MPEG2
Power consumption (standby)	0.1 W
Power consumption (typical)	23 W
Signal-to-Noise Ratio (SNR)	100 dB
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	0.005 %
