Onkyo BD-SP809 Service Manual

1-2-1 B4NLBSP
LASER BEAM SAFETY PRECAUTIONS
This BD player uses a pickup that emits a laser beam.
The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep
your eyes at least 11.8 inches (30 cm) away from the pickup lens when the diode is turned on. Do not look directly
at the laser beam.
CAUTION: Use of controls and adjustments, or doing procedures other than those specified herein, may result in
hazardous radiation exposure.
Location: Inside Top of BD mechanism.
Do not look directly at the laser beam coming
from the pickup or allow it to strike against your
skin.
Drive Mechanism Assembly
Laser Beam Radiation
Laser Pickup
Turntable

Onkyo BD-SP809 Specifications

General

3D	Yes
Depth	313 mm
Wi-Fi	No
Width	435 mm
Height	104 mm
Weight	4700 g
Display	-
Device type	Blu-Ray player
Package depth	411 mm
Package width	551 mm
Product color	Silver
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS-HD
Package height	217 mm
Package weight	6100 g
Cables included	AV
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Dimensions (WxDxH)	- mm
Disc types supported	BD-R, BD-RE, BD-ROM, CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW
Dynamic range (1kHz)	98 dB
USB 2.0 ports quantity	1
Audio formats supported	MP3, WMA
Image formats supported	JPG
Video formats supported	AVCHD, DIVX, MKV, MPEG1, MPEG2
Power consumption (standby)	0.1 W
Power consumption (typical)	23 W
Signal-to-Noise Ratio (SNR)	100 dB
Audio output channels	5.1 channels
Total Harmonic Distortion (THD)	0.005 %
