Page #42 background imageLoading...
Page #42 background image
42
Troubleshooting—Continued
Playback jumps.
The CD receiver is being subjected to vibration or the disc is scratched or dirty (see page 12).
Can’t add tracks to the playlist for memory playback.
Make sure there’s a disc in the CD receiver. Also, you can only add valid track numbers. For example, if the CD
contains 11 tracks, you cannot add track #12.
The disc will not play.
Make sure the disc has been loaded correctly, with the label-side facing up.
Check to see if the surface of the disc is dirty (see page 12).
Some CD-R/RW discs may not be playable (see page 12).
It takes a long time for playback to start.
It may take the CD receiver a while to read CDs that contain many tracks or files.
Can’t Play MP3/WMA/AAC discs.
Use only ISO 9660 Level 1 or Level 2 format discs (see page 12).
The disc has not been finalized. Finalize the disc.
MP3/WMA/AAC files without a “.MP3/.WMA/.AAC” or “.mp3/.wma/.aac” filename extension are not recognized.
Reception is noisy, stereo FM reception suffers from hiss, the Auto Preset function doesn’t preset all
stations, when tuned to a stereo FM station.
Check the antenna connections (see page 14).
Change the position of the antenna.
Move the CD receiver away from a nearby TV or computer.
Cars or airplanes can cause noisy interference.
The radio signal will be weakened if it has to pass through a concrete wall before reaching the antenna.
Try setting FM mode to mono (see page 31).
Move power cords and speaker cables as far away as possible from the tuner’s antenna.
When listening to an AM station, noise may be heard when you operate the remote controller.
If none of the above improves the reception, install an outdoor antenna.
If a power outage occurs or the power cable is disconnected.
If the preset stations are lost, preset them again (see pages 31, 32).
Can’t adjust the frequency of the radio.
Use the Fast Reverse and Fast Forward [5]/[4] buttons to change the frequency of the radio (see page 31).
RDS doesn’t work.
The FM station you are tuned to doesn’t support RDS.
Install an outdoor FM antenna.
Change the position or direction of your outdoor FM antenna.
Move the FM antenna as far away as possible from fluorescent lights.
The remote controller doesn’t work properly.
Make sure the batteries have been installed with the correct polarity (+/–) (see page 7).
Replace both batteries with new ones. (Do not mix different types of batteries or new and old batteries.)
The remote controller is too far away from the CD receiver, or there’s an obstacle between them (see page 7).
The CD receiver’s remote control sensor is being subjected to bright light (inverter-type fluorescent light or sunlight).
The CD receiver is located behind the glass doors of a audio rack or cabinet.
CD Playback
Tuner
Remote Controller

Table of Contents

Other manuals for Onkyo CS-N755

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo CS-N755 and is the answer not in the manual?

Onkyo CS-N755 Specifications

General IconGeneral
KaraokeNo
Impedance4 Ω
Bass reflexYes
Speaker type2-way
Frequency range10 - 10000 Hz
RMS rated power44 W
Woofer diameter120 mm
Tweeter diameter25 mm
Number of speakers2
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.4 %
TypeHome audio mini system
Product colorBlack, Silver
Number of optical discs1 discs
Disc types supportedCD, CD-R, CD-RW
Playback disc formatsCD audio
Audio formats supportedAAC, FLAC, MP3, OGG, WAV, WMA
AM band range522 - 1.611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity40
Internet radio services supportedvTuner
Display typeLCD
Headphone outputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Speaker depth258 mm
Speaker width154 mm
Speaker height245 mm
Apple docking compatibilityNot supported
Power sourceAC
Input voltage220-230 V
Input frequency50 - 60 Hz
Power consumption (standby)0.26 W
Power consumption (typical)74 W
Volume controlRotary
Weight and Dimensions IconWeight and Dimensions
Depth331 mm
Width215 mm
Height119 mm
Weight4800 g
