Onkyo HT-R592 Service Manual

DEBUG MODE-2
AUDIO DEBUG MODE-2/3
HT-R592/ 2295
NIC/DEC/SPI Busy/Exec wait
0
Stable state
Internal state Inferred state
1
NIC
2
DEC
3
NIC+DEC
9
Exec wait + NIC
8
Exec wait
If you stop at these numbers, please check the DSP Sequence.
If the stop remains "1" is indicated, it is possible that there is an abnormality in
the connection between the microcomputer and the NIC.
4
SPI Busy
5
SPI Busy + NIC
6
SPI Busy + DEC
7
SPI Busy + NIC + DEC
F
Exec wait + SPI Busy
+ NIC + Dec
E
Exec wait + SPI Busy
+ DEC
D
Exec wait + SPI Busy
+ NIC
C
Exec wait + SPI Busy
B
Exec wait + NIC+DEC
A
Exec wait + DEC
Display
contents
Please check if the input signal Dolby / DTS / AAC / PCM from Coax or OPT.
If the stop remains “2” is indicated, it is possible that there is an abnormality
in the connection between the DIR and the DSP.
There is a case of "2" for the state to stop or pause playback equipment.
And it is normal.
If the stop in these numbers, it is possible that there is an abnormality in
the connection between the DSP and the microcomputer.
If the stop remains "3" is indicated, it is possible that there is an abnormality in
the connection between the microcomputer and the NIC.
