Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
 5. Volume
Change the Volume settings.
Setting Item Default Value Setting Details
Mute Level -∞ dB Set the volume lowered from the listening volume
when muting is on. Select a value from "-∞ dB",
"-40 dB" and "-20 dB".
Maximum Volume O󰀨 Set the maximum value to prevent the volume from
becoming too loud. Select a value from "O󰀨", and
"50" to "99".
Power On Volume Last Set the volume level of when the power is turned
on. Select a value from "Last" (Volume level before
entering standby mode), "Min", "1" to "99" and
"Max".
• You cannot set a higher value than that of
"Maximum Volume".
Headphone Level 0 dB Adjust the output level of headphones. Select a
value between "-12 dB" and "+12 dB".
4. Source
 1. IntelliVolume
Adjust the volume level when there are di󰀨erences in volume level among multiple
devices connected to this unit. Select the input selector to make the setting.
Setting Item Default Value Setting Details
IntelliVolume 0 dB Select a value between "-12 dB" and "+12 dB". Set
a negative value if the volume of the target device is
larger than the others and a positive value if smaller.
To check the audio, play back the connected device.
• This function does not work in Zone B.
 2. Name Edit
Set an easy name for each input. The set name appears on the main unit’s
display. Select the input selector to make the setting.
Setting Item Default Value Setting Details
Name Edit Input name 1. Select a character or symbol with the cursors,
and press ENTER.
Repeat this operation to input up to 10 characters.
"A/a": Switches between upper and lower cases.
(Pressing MODE on the remote controller also
toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
" ": Removes a character on the left of the cursor.
"Space": Enters a space.
• Pressing CLEAR on the remote controller will
remove all the input characters.
2. After inputting, select "OK" with the cursors, and
press ENTER.
The input name will be saved.
To restore the name to the default value, press
CLEAR on the remote controller on the input
screen. Then while nothing is entered, select "OK",
and press ENTER.
• To name a preset radio station (FM), press TUNER on the remote controller, select FM,
and select the preset number.
• This cannot be set if the "BLUETOOTH" input is selected.
