Onkyo HT-S5910 User Manual

110
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Spring type color coded
Other
Non-magnetic shielding
 Subwoofer (SKW-593)
Speaker Type
Bass Reex
Input sensitivity/Impedance
540 mV/20 kΩ
Drivers
10" (25 cm) Cone
Frequency Response
25 Hz - 150 Hz
Dimensions (W × H × D) (Including terminal projections)
317.5 mm × 463 mm × 398 mm
12-1/2" × 18-1/4" × 15-11/16"
Weight
9.6 kg (21.2 lbs)
Rated output Power (IEC)
120 W at 4ohms, 100 Hz, 1% THD
Maximum Effective Output Power
130 W at 4ohms, 100 Hz, 10% THD
Audio input
1 (RCA analog mono)
Power supply
AC 120 V, 60 Hz
Power consumption
35 W
Other
Auto Standby function
Non-magnetic shielding
Specications and features are subject to change without notice.
 License and Trademark

Onkyo HT-S5910 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
4Ω speaker support	No
Audio output channels	5.1.2 channels
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	115 W
Display	LCD
Product color	Black
Audio decoders	Dolby Atmos
Damping factor	60
Amplifier output power	925 W
HDMI in	4
Composite video in	3
Digital audio coaxial in	1
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	0
Audio (L/R) out	7
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	328 mm
Width	453 mm
Height	160 mm
Weight	7800 g
