Onkyo TX-RZ800 User Manual

4/60 PAGE
TX-RZ800(B)MDC
PC BOARD PARTS LIST
U001 BAAMP-1779-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D6000 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6000 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6002 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6002 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6003 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6003 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6004 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6004 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6005 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6005 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6006 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6006 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6010 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6010 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6011 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6011 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6012 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6012 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6013 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6013 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6014 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6014 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6015 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6015 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6016 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6016 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6020 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6020 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6021 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6021 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6022 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6022 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6023 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6023 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6024 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6024 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6025 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6025 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6026 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6026 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6908 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6908 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D9001 DIODE S1WB(A)60B-7062 1 22380377R2
1
D9002 SPECIFIED DIODE P6SMB200A-M3/52T 1 225505R2
1
D9003 DIODE US1K-E3/61T 1 22380376R2
1
D9004 DIODE RF301BM2STL 1 22380388R2
1
D9004 or DIODE RF301B2STL ( 1) 22380374R2
1
D9006 DIODE M1FL20U 1 223276R2
1
D9008 DIODE RB050M-30GTR 1 22380373R2
1
D9011 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D9011 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D9012 ZENER DIODE DZ2J360M0L 1 224763600R2
1
D9012 or ZENER DIODE UDZS36B ( 1) 224553600R2
1
D9013 SPECIFIED DIODE P6SMB20A-M3/52 1 225515R2
1
D9018 ZENER DIODE DZ2J200M0L 1 224762000R2
1
D9018 or ZENER DIODE UDZS20B ( 1) 224552000R2
1
D9028 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D9028 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
Q6000 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6001 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6002 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6003 TRANSISTOR 2SC2412K-R 1 2214653R2

Onkyo TX-RZ800 Specifications

General

Receiver type	Surround
Input sensitivity	300 mV
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Dynamic power per channel (3 Ohm)	300 W
Dynamic power per channel (4 Ohm)	250 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	185 W
Display	-
Product color	Silver
Damping factor	40
Apple docking compatibility	Not supported
AM band range	530 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Card reader integrated	No
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	90 W
Package depth	521 mm
Package width	582 mm
Package weight	20500 g
THX-certified	THX Select2 Plus
Audio formats supported	AAC, Vorbis, WAV, WMA, OGG, FLAC, MP3
HDMI in	8
Audio (L/R) in	9
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	3

Weight and Dimensions

Depth	433.5 mm
Width	435 mm
Height	201.5 mm
Weight	17000 g
