Additional information
7
7
35
33
4
2
Resetting the main unit
Use this procedure to reset all the receiver’s settings to the
factory default. Use the front panel controls to do this.
1
Switch the receiver into standby.
2
While holding down
STEREO
, press and hold
Í
ON/STANDBY
for about two seconds.
3
When you see RESET? appear in the display, press
SURROUND
.
OK? shows in the display.
4
Press
DSP
to confirm.
OK appears in the display to indicate that the receiver
has been reset to the factory default settings.
Cleaning the unit
•
Use a polishing cloth or dry cloth to wipe off dust and dirt.
•
When the surface is dirty, wipe with a soft cloth dipped in
some neutral cleanser diluted five or six times with water,
and wrung out well, and then wipe again with a dry cloth.
Do not use furniture wax or cleansers.
•
Never use thinners, benzine, insecticide sprays or other
chemicals on or near this unit, since these will corrode the
surface.
Specifications
Audio section
Rated power output
Front, Center, Surround
. . . . . . . . . . . . . . . . 135 W per channel (1 kHz, 6 Ω, 1 %)
. . . . . 100 W per channel (20 Hz to 20 kHz, 8 Ω, 0.09 %)
Total Harmonic Distortion
. . . . . . . . . . . . . . . . 0.06 % (20 Hz to 20 kHz, 8 Ω, 50 W/ch)
Frequency response (LINE Direct mode)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Hz to 100 kHz dB
Guaranteed speaker impedance . . . . . . . . . . . . 6 Ω to 16 Ω
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 kΩ
Signal-to-Noise Ratio (IHF-A network, 1 kΩ shorted)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106 dB
Video Section
Signal level
Composite . . . . . . . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Tuner Section
Frequency Range (FM) . . . . . . . . . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . .75 Ω unbalanced
Frequency Range (AM)
9 kHz Step . . . . . . . . . . . . . . . . . . . .531 kHz to 1602 kHz
10 kHz Step . . . . . . . . . . . . . . . . . . .530 kHz to 1700 kHz
Antenna (AM) . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
BLUETOOTH section
Version. . . . . . . . . . . . . BLUETOOTH Specification Ver. 3.0
Output . . . . . . . . . . . . . BLUETOOTH Specification Class 2
Estimated line-of-sight transmission distance*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . About 10 m
Frequency range . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4 GHz
Supported BLUETOOTH profiles . . . . . . . . . . . . . . . . .A2DP
Supported Codec . . . . . . . . . . .SBC (Subband Codec), AAC
* The line-of-sight transmission distance is an estimate.
Actual transmission distances supported may differ
depending on surrounding conditions.
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . Type A (19-pin)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . 5 V, 55 mA
USB terminal . . . . . USB2.0 Full Speed (Type A) 5 V, 0.5 A
Miscellaneous
Power Requirements . . . . AC 220 V to 240 V, 50 Hz/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . 220 W
In standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 W
Dimensions. . . . 435 mm (W) x 168 mm (H) x 326.5 mm (D)
Weight (without package). . . . . . . . . . . . . . . . . . . . . . 8.0 kg
