Onkyo TX-SR606 Service Manual

IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-15
Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3
SYSTEM BLOCK DIAGRAM
TX-SR606
Lout
REC
Lch
Rout
Input
ATT
Out L
for
ADC
REC
AGND
Out R
for
ADC
Rch
AVCC
Multi
Rin
Multi
Lin
3
4
5
6
7
8
9
1
2
Tone
Rch Tone
Bass &
Lch Tone
10
11
3
4
5
6
7
8
9
1
2
10
11
SLout
Multi
SLin
Multi
SRin
Cout
SWout
Multi
Cin
Multi
SWin
SBLout
Multi
SBLin
Multi
SBRin
AVEE
SUB
SUB
MCU I/F
CLOCK DATA
Bass &
Volume
Volume
Input
ATT
mono
SBRout
SRout
Volume
Volume
Volume
Volume
Volume
Volume
Volume
Volume
Input selector
Input selector
Volume
Volume
Treble
Treble

Onkyo TX-SR606 Specifications

General

Frequency range	50 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Connectivity technology	Wired
Product color	Silver
Dimensions (WxDxH)	435 x 374.7 x 174.3 mm
Power consumption (typical)	550 W

Weight and Dimensions

Weight	11400 g
