Onkyo TX-SR606 Service Manual

TX-SR606
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-19
Q8001 : FLI30502 (LCD TV Controller with Worldwide Sandard Sound Processor
and HDMI Receiver)-1/12
BLOCK DIAGRAM
Pattern
Generator
Input Capture
Audio
Processing
Engine
Audio
Output
Interface
Audio
Input
Interface
SIF Decoder
8/16/24 Bit
DDC2bi
Interface
CSD
Controller
Output
Formatter
2-wire
Controller
GPIOs
Digital
Audio Input
Module
Analog
Audio Input
Module
Video
Decoder
SPDIF
/ I2S
Input
Audio Processing
Audio Control Interface
Image Processing
R+L to Speaker Amp
Sub-woofer
Headphone Output
I2S
SPDIF
Line Out (R+L)
Input
Format
Measurement
Low
Bandwidth
ADC
IR
Interface
Embedded
Micro-processor
ROM
Interface
RAM
Interface
Analog Front
End
(Video)
(SIF-Audio)
Sync Stripper
Video
Decoder
VBI Slicer
Sync
Processing
Internal Micro-
processor Bus
External ROM
CVBS
Inputs
NOISE REDUCTION
BLOCK(CMF)
Scaling
Engine
DCDi-Edge
Correction
Holizontal
Enhancement
ACC / ACM-3D
3 x 3 Matrix
CLUTs
Overlay
Main Audio
Output
(DAC)
Digital
Audio
Output
Digital
Audio
Output
(DAC)
FAROUDJA
DCDI
EDGE
Digital Video
Inputs

Onkyo TX-SR606 Specifications

General

Frequency range	50 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Connectivity technology	Wired
Product color	Silver
Dimensions (WxDxH)	435 x 374.7 x 174.3 mm
Power consumption (typical)	550 W

Weight and Dimensions

Weight	11400 g
