Optoma Pico PK320 User Manual

4
C
harge the Battery poWer on / off
4
PUSH
1
1. Make sure the projector is turned
off.
2. Insert the plug. (

)
3. Connect the charger. (

~

)
4. During charging, the LED indicator
lights red. (

)
5. The LED indicator turns green
when the battery is fully charged.
This process may take up to 2.5
hours.
3
2
Press the Power button to turn the
projector on or off.
Forrsttimeuse,theLanguage
screen appears.
1. Highlight the desired language.
(
)
2. Select the item. ( )
<Note>
1. The battery will not charge while the
projector is operating.
2. For LED indicator information, see page
23.
3. After the projector is turned off, the battery
may not start charging right away due to
overtemperatureprotection.Theprojector
will automatically start charging once it
cools off.
4.Thebatteryhasalifespanandagesevery
time it is charged and discharged. It will
gradually loose its charging capability as it
ages. Replace the battery at the end of its
lifespan.
When the LED indicator lights red,
the battery is low. Replace the battery
immediately or connect the power
adapter to charge the battery.
4
connect
I
nput
S
ource - vga / compoSIte / hDmI
1
2
Connect the VGA / Component /
HDMIdeviceusinganappropriate
cable. (

~

)
Inserttheuniversalconnector
with the arrow mark facing down.
1
2
1
2
or
or
connect
I
nput
S
ource - vIDeo In / auDIo In
1. Connect the AV input source.
(

~

)
2. Connect external speakers to the
audio out connector of the projector.
(

)
<Note>
1. All other brand and product names are
trademarks or registered trademarks of
theirrespectivecompanies.
2.Thecablesconnectingthevideooutput
devicesarenotsupplied,pleasecontact
thedevicevendor.
3. iPod nano/iPod touch/iPhone/iPod classic
(version5andabove)
4. Designed for iPod/iPhone/Mobile phone/
PMP with TV out functions. Using with
deviceswithaudiosignalvoltage>0.3Vrms
is not recommended.
5. The optional USB cable for iPod Connector
isusedtochargetheiPoddeviceusinga
computer.
3
1
2
1
2
1
2
or
or
Audio input
only
Forvideoand
audio input
<Note>
Component and HDMI cables are not
included in the package.

Optoma Pico PK320 Specifications

General

Projection distance	0.13 - 6 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	40 - 150 \
Projector native resolution	WVGA (854x480)
I/O ports	HDMI, VGA, AV
Audio input	Yes
Audio system	1.0
RS-232 ports	0
Compatibility	NB, iPhone, iPad2, Blackberry, PC
Power supply type	AC/DC
Dimensions (WxDxH)	120 x 70 x 30 mm
Connectivity technology	Wired
Focus	Manual
Throw ratio	1.8 - 2.1:1
Zoom capability	No
Focal length range	- mm
Light source type	LED
Service life of light source	20000 h
RMS rated power	1 W
Audio formats supported	MP3, MS-ADPCM, WMA
Image formats supported	BMP, JPG
Video formats supported	3GP, ASF, AVI, FLV, MOV, MP4, TS, WMV
Document formats supported	DOC, DOCX, PDF
Number of built-in speakers	1
USB connector type	Micro-USB A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	miniSD, miniSDHC
Maximum memory card size	32 GB
Internal storage capacity	1 GB
Noise level	- dB
Product type	Portable projector
Product color	Black
Market positioning	Portable
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Battery life (max)	1.5 h
Power consumption (standby)	- W
Cables included	AUX, USB, VGA
Remote control type	IR
Sustainability certificates	RoHS

Weight and Dimensions

Depth	70 mm
Width	120 mm
Height	30 mm
Weight	250 g
