Orbit T944 User Manual

18
SPARTS LIST
No Description Specification Qty No Description Specification Qty
1 MAIN FRAME
Left /right side
tube60*30*2.0
1 38 TUB PLUG 2
2 BASE FRAME
Left/right
connect
tube80*40*2.0
1 39 TUB PLUG 2
3 LEFT UPRIGHT 100*40*2.0 1 40 FOAM 2
4 RIGHT UPRIGHT 100*40*2.0 1 41 SIDE RAIL 2
5 COMPUTER BRACKET 1 42 NON-SLIP PAD 4
6 INCLINE SUPPORT FRAME 1 43 MOTOR BOTTOM COVER 1
7 REAR INCLINE FRAME 1 44 SLIDING BLOCK 2
8 SLIDING BLOCK 2 45 BELT 1
9 MOTOR BRACKET 1 46 FOOT PAD 2
10 HANDLE BAR BRACKET Φ31.8*2.0 1 47
RING PROTECTING WIRE
PLUG
2
11 LEFT HANDLE BAR 70*41.6*2.0 1 48 WHEEL PROTECT COVER 2
12 RIGHT HANDLE BAR 70*41.6*2.0 1 49 TRANSPORT WHEELS 4
13 Z-SHAPE SENSOR CONNECT 1 50 ADJUSTING ROLLER 2
14 FRONT ROLLING 1 51 CUSHION PAD1 RED 2
15 REAR ROLLING 1 52 CUSHION PAD2 BLUE 2
16 SLIDE RAIL ROD 2 53 CUSHION PAD3 BLACK 2
17 REAR INCLINE BUSHING 2 54 TAPER CUSHION PAD 2
18 SPRING 1 55 INNER TUBE PLUG 4
19 BOLT 2 56 INNER TUBE PLUG 2
20 5#ALLEN WRENCH 5mm 1 57 RUNNING BELT 1
21 6#ALLEN WRENCH 6mm 1 58 60*30 INNER TUBE PLUG 2
22 PHILIP SCREW DRIVER S=13、14、15 1 59 MOTOR TOP COVER 1
23 WHEELS BUSHING 4 60 PLASTIC PAD 2
24 CYLINDER 2 61 LEFT BOTTLE FRAME 1
25 BOLT 2 62 BOLT M8*20 5
26 COMPUTER TOP COVER 1 63 BOLT M8*25 4
27 COMPUTER BOTTOM COVER 1 64 BOLT M8*40L 20 4
28 COMPUTER PANEL 1 65 BOLT M8*50L15 3
29
TOP COVER FOR ADJUSTING
SPEED BUTTON
1 66 BOLT M8*60L15 1
30
BOTTOM COVER FOR
ADJUSTING SPEED BUTTON
1 67 BOLT M10*20 12
31
SIDE COVER FOR
ADJUSTING SPEED BUTTON
2 68 BOLT M10*30L15 2
32
LEFT WATER BOTTLE
BRACKET
1 69 BOLT M10*45L15 1
33
RIGHT WATER BOTTLE
BRACKET
1 70 BOLT M10*65L15 1
34 LEFT BACK COVER 1 71 BOLT M8*30 4
35 RIGHT BACK COVER 1 72 BOLT
M6*28
6
36 REAR ADJUSTING KNOB 2 73 BOLT M6*32 2
37 RIGHT BOTTLE FRAME 1 74 BOLT M8*15 2

Orbit T944 Specifications

General

Brand	Orbit
Model	T944
Category	Treadmill
Language	English
