Getting Started
Charging the batteries
(using the charging pods) - UHF2190
a. Insert the small plug on the
end of the mains adaptor into
the power-in connection jack
at the back of the desktop
charger.
b. Plug the mains adaptor into a
230V AC, 50Hz main socket
with the switch on the socket
set to Off.
c. Switch On the main socket.
d. Place the units in the charge cradle in an upright position. The
charge LED indicators will light up.
It takes about 10 hours to fully charge the batteries if they are
completely run down. New batteries take up to 14 hours to
fully charged.
Important:Always turn off
the units when charging.
This will shorten the
charging time.
Main socket
Removing the Belt Clip
Pull the Belt Clip latch forward
(away from the unit)
While pulling the Belt Clip latch,
push up the Belt Clip as shown in
Figure1.
Installing the Belt Clip
Slide the Belt clip into the slot as
shown in Figure2.
A “click” indicates the Belt clip is
locked into position.
Figure 1
Figure 2
Belt Clip latch
OR011253 UHF2190_2195 User Guide_11-07-14.indd 10 2014/11/7 14:31:10
