Page 39
Installation and Operation Manual - Osburn 3500
APPENDIX 1: DOOR OVERLA
Y INST
ALLA
TION
Position the overlay
(A)
on the door frame and secure it in place fr
om behind using the nuts
(B)
.
T
o ease the installation, do not tighten the nuts until they are all installed.
A
B
Note: It is not necessary to r
emove the glass to install the overlay
.
38
40
