Form No. OVSM-0116
5
Model Voltage Watts Amps Phase Hertz Plug Configuration Unit Weight
S1200
208/240 5408 26 1 60 NEMA 6-30P 167 lbs. (76 kg)
S1200CSA
208 4992 24 1 60 NEMA 6-30P 167 lbs. (76 kg)
S1200 (HW)
208/240 6656 32 1 60 NEMA 6-50P 167 lbs. (76 kg)
S2000
208/240 9152/11760 44/49 1 60 NEMA 6-50P 230 lbs. (104 kg)
S2000CSA
208 8320 40 1 60 NEMA 6-50P 230 lbs. (104 kg)
MODEL DESIGNATION
SPECIFICATIONS
Electrical Rating Chart
S X X X X
Oven Type:
S = Shuttle
Model Number:
1200 = 12" x 12" Cavity With Catalyst
2000 = 20" x 20" Cavity With Catalyst
2000NC = 20" x 20" Cavity, No Catalyst
NOTE: Ovention Shuttle Ovens with the voltage shown as
“208/240” are designed to accept either 208 VAC or
240 VAC. The oven will adjust automatically to the input
voltage.
NOTE: The specification label is located on the left side of the
unit. See the label for the serial number and verification
of unit electrical information.
Plug Configuration
Units are equipped with an electrical cord and plug appropriate
for the electrical rating of the unit. Unit must be connected to a
dedicated circuit.
ELECTRIC SHOCK HAZARD: Plug unit into a properly
grounded electrical receptacle of the correct voltage, size,
and plug configuration. If plug and receptacle do not
match, contact a qualified electrician to determine and
install proper voltage and size electrical receptacle.
Plug Configuration
NOTE: Receptacle not supplied by Ovention.
Temperature Range
The operating temperature range of the Shuttle Ovens is
300°–525°F (149°–274°C).
