OWC ENVOY PRO EX User Guide

03
1.1 SYSTEM REQUIREMENTS
- Operating System
- Mac: macOS 10.12 or later
- PC: Windows 10 or later
- Hardware
- Mac or PC with a Thunderbolt 3 or USB-C port
- USB-C hosts with USB 3.1 Gen 1 will function normally but Thunderbolt
3 or USB 3.1 Gen 2 are recommended for best performance.
- NVMe M.2 SSD in 2280 form factor with M-key connector
- Not compatible with AHCI PCIe M.2 SSDs
- Not compatible with SATA M.2 SSDs
1.2 PACKAGE CONTENTS
1.3 ABOUT THIS GUIDE
The instructions below are for customers who purchased the Envoy Pro EX with USB-C enclosure and need
to install their own NVMe M.2 SSD. This device requires an M.2 drive with a 2280 form factor. Please contact our
customer service team if you still have questions after reviewing the steps that follow.
INTRODUCTION
OWC Envoy Pro EX
with USB-C
USB 3.1 Gen 2 cable
(Type-C to Type-C)
Screw packet¹ & Rubber feet
INTRODUCTION
1. Assembly requires a Torx T5 driver.

OWC ENVOY PRO EX Specifications

General

NVMe	Yes
Interface	PCI Express 3.0
Read speed	1250 MB/s
Write speed	- MB/s
SSD capacity	8000 GB
SSD form factor	M.2
Wi-Fi	-
USB version	3.2 Gen 2 (3.1 Gen 2)
USB connector	USB Type-C
Data transfer rate	10 Gbit/s
Thunderbolt version	3
Certification	FCC
Product color	Silver
Housing material	Aluminum
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	115 mm
Width	65 mm
Height	9 mm
Weight	148 g
