15
Elektronic connectors
Term no. Descripon
1. Baery + 24 V, connected to P-LIGHT®
baery(factory-connected).
2. Baery – Gnd, connected to P-LIGHT®
baery(factory-connected).
3. Input Gnd (-) from truck/trailer Midi =
1.5mm²/Maxi=2.5mm².
4. Input +24V “Lighng circuit 1” from
trailer’s couplingconnector. Midi=1.5mm²
/Maxi=2.5mm².
5. Output +24V “Lighng circuit 1”*,
connectedtoparking andside lightswhich
aretoremainonwhiledriving,andP-LIGHT®
forshort-term parking.NOTE: Must not be
connectedtocablingconnectedtoterminal
4or6.
6. Input +24V “Lighng circuit 2” from
trailer’s couplingconnector. Midi=1.5mm²
/Maxi=2.5mm².
7. Output +24V “Lighng circuit 2”*,
connectedtoparking andside lightswhich
aretoremainonwhiledriving,andP-LIGHT®
forshort-term parking.NOTE: Must not be
connectedtocablingconnectedtoterminal
4or6.
8. Input +24V “Opon” Maxi only, Midi =
no funcon), direct operaon to terminal
9. If, for example, you connect strobes to
terminal 9, it is possible to connect the
trailer’sreversingcircuithere,thisacvates
thestrobeswhenthevehicleisreversing.
9. Output +24V “Opon”* e.g. strobes/
worklighng,max.200W.(Maxi=Acvated
bypushbuon2,Midi=Nofuncon).
10.Output+24V”AUX”*.Always+24Veven
ifthetruckisnotconnected,norcontrolled
byanypushbuon.Intendedforoperaonof
e.g.anexternalradiocontrolorequipment
with its own keypad, e.g. cabinet lighng,
etc., cable is prepared up to toggle switch
wheretherequiredequipmentisconnected:
Midi=max.50W/Maxi=max.200W.
*=Fiedwithbaery/energymonitor,see
thenextpageformoreinfo.
Maximumnumberofsimultaneoustake-os
Midi=max100W/Maxi=max270W
Termno.Descripon
21.Nofuncon.
22.Nofuncon.
23 -Cable to pushbuon 2 “Opon”
(acvatesterminals9).
24.+Cable to pushbuon 2 “Opon”
(acvates terminals9).“Opon”Maxi only,
Midi=nofuncon).
25.-Cable to pushbuon 1 “Parking”
(acvatesterminals5and7).
26.+Cable to pushbuon 1 “Parking”
(acvatesterminals5and7).
Thecablefuseholderisedatthebaeries
and the fuse (20A) must be ed aer
conneconbutbeforeP-LIGHT®isused.
(Note: A spark may occur when the
electronicsstartandarechargedup)
