3 Product Specifications
3.1. CS-A18DKD CU-A18DKD
Unit CS-A18DKD CU-A18DKD
Power Source (Phase, Voltage, Cycle) ,V,Hz Single, 220 - 230, 50
Cooling Capacity kW (BTU/h) 5.30 (18,100) - 5.30 (18,100)
Heating Capacity kW (BTU/h) 5.65 (19,300) - 5.70 (19,400)
Moisture Removal l/h (Pint/h) 2.9 (6.1)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m
3
/min (cfm) Cooling; 13.1 (460) - 13.1 (460) 28.6 (1,010) - 31.1 (1,100)
Heating; 14.2 (500) - 14.2 (500)
Me m
3
/min (cfm) Cooling; 14.5 (510) - 14.5 (510) —
Heating; 14.7 (520) - 14.7 (520)
Hi m
3
/min (cfm) Cooling; 15.3 (540) - 15.3 (540) 50.7 (1,790) - 52.7 (1,860)
Heating; 16.0 (560) - 16.0 (560)
SHi m
3
/min (cfm) Cooling; 16.0 (560) - 16.0 (560) —
Noise Level dB (A) Cooling; High 43 - 43, Low 38 -38 Cooling; High 53 - 54
Heating; High 42 - 42, Low 38 -38 Heating; High 54 - 55
Electrical Data Input Power kW Cooling; 1.72 - 1.76
Heating; 1.65 - 1.71
Running Current A Cooling; 8.0 - 7.8
Heating; 7.7 - 7.6
EER W/W (BTU/hW) Cooling; 3.08 - 3.01 (10.52 - 10.28)
COP W/W (BTU/hW) Heating; 3.42 - 3.33 (11.70 - 11.35)
Starting Current A 44.5
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 3-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 29 - 17/32 (750)
Width inch (mm) 39 - 9/32 (998) 34 - 7/16 (875)
Depth inch (mm) 9 - 1/16 (230) 13 - 19/32 (345)
Net Weight lb (kg) 24 (11.0) 132 (60.0)
Compressor Description — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.5
6
CS-A18DKD CU-A18DKD / CS-A24DKD CU-A24DKD
