21
8.2 CS-C18MKP-7 CU-C18MKP-7
Resistance of Outdoor Fan Motor Windings
Resistance of Compressor Windings
MODEL CU-C18MKP-7 MODEL CU-C18MKP-7
CONNECTION CWA951705 CONNECTION 2KS314D5BA06
BLUE-YELLOW 223.0 C-R 1.853
YELLOW-RED 255.6 C-S 4.879
Note: Resistance at 25°C of ambient temperature. Note: Resistance at 20°C of ambient temperature.
