7. Adjusting the Wind Direction
16
(EN)
• Never try to manually move the fl ap (up-down wind direction plate) that is
operated by the remote controller.
• When the unit stops, the fl ap (up-down wind direction plate) automatically
faces downwards.
• When the unit is in heating standby, the fl ap (up-down wind direction plate)
faces upwards. Also, bear in mind that the fl ap starts swinging after the
heating standby mode is released, but the display on the remote controller
indicates Auto Flap during standby heating as well.
CZ-RWSU3/CZ-RWSU2N/
CZ-RWSD2/CZ-RWSL2N/
For wall mounted type indoor unit
(CZ-RWSK2)/CZ-RWST3N
Setting the Wind Direction
While the unit is operating, every time
you press , the direction the fl ap
faces changes.
Setting Flap to Swing
If you press
to set the fl ap (up-
down wind direction plate) in its most
downward facing position, and then
press
again, is displayed
and the fl ap swings automatically up
and down.
Stopping Flap Swing
If you press
again while the fl ap
is swinging, you can stop the fl ap from
swinging and set it in place as
desired. Thereafter, if you press ,
you can set the wind direction starting
from the most upward position.
• When the unit is in the Cool or Dry
mode, the fl ap cannot stop facing
downwards. If you try to stop the
fl ap from swinging while it is facing
downwards, it will continue moving
until it is in the third position from
the top.
In the Heat Mode
Please face the fl ap
(up-down wind
direction plate)
downwards. If it faces
upwards, the warm air
will not reach the fl oor level.
In the Cool or Dry Mode
Please face the fl ap
(up-down wind
direction plate)
upwards. If the plate
faces downwards,
condensation may
form and drip from
around the air outlet.
In the Fan Mode
Initial setting
In All Modes
Moves constantly
Displays with Swing Stopped
Fan/Heat
modes
Cool/Dry
modes
Initial setting
Initial setting
To Next Page
