95
VQT2J46
Reference
Specifications
Recording system DVD-RAM : DVD Video Recording format
DVD-R : DVD-Video format
DVD-R DL (Dual Layer) : DVD-Video format
DVD-RW : DVD-Video format
+R
+R DL (Double Layer)
+RW
Recordable discs
DVD-RAM: 2X SPEED (Ver. 2.0),
2-3X SPEED (Ver. 2.1), 2-5X SPEED (Ver. 2.2)
DVD-R: 1X SPEED (Ver. 2.0), 1-4X SPEED (Ver. 2.0),
1-8X SPEED (Ver. 2.0), 1-16X SPEED (Ver. 2.1)
DVD-R DL (Dual Layer): 2-4X SPEED (Ver. 3.0), 2-8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1-2X SPEED (Ver. 1.1),
2-4X SPEED (Ver. 1.2), 2-6X SPEED (Ver. 1.2)
+R: 2.4X SPEED (Ver. 1.0), 2.4-4X SPEED (Ver. 1.1),
2.4-8X SPEED (Ver. 1.2), 2.4-16X SPEED (Ver. 1.3)
+R DL: 2.4X SPEED (Ver. 1.0), 2.4-8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4-4X SPEED (Ver. 1.2)
Recording time Maximum 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour, SP: Approx. 2 hours
LP: Approx. 4 hours, EP: Approx. 6 hours/8 hours
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours, SP: Approx. 110 hours
LP: Approx. 221 hours, EP: Approx. 331 hours/441 hours
Playable discs
DVD-RAM : DVD Video Recording format, JPEG
DVD-R : DVD-Video format, MP3
§1
, WMA
§1
, JPEG
§1
, DivX
§1
DVD-R DL (Dual Layer) : DVD-Video format,
MP3
§1
, WMA
§1
, JPEG
§1
, DivX
§1
DVD-RW : DVD-Video format, DVD Video Recording format
+R, +R DL (Double Layer), +RW
DVD-Video, CD-Audio (CD-DA), Video CD, SVCD
§2
CD-R/CD-RW : CD-DA
§
1
, Video CD
§
1
, SVCD
§
1
§
2
, MP3
§
1
, WMA
§
1
,
JPEG
§
1
, DivX
§
1
Internal HDD capacity 250 GB
Optical pick-up System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER specification
Class 1 LASER Product (Pickup)
Wave length:
Laser power:
No hazardous radiation is emitted with the safety protection
Audio
Recording system: Dolby Digital 2ch, Linear PCM (XP mode)
Audio in: AV1/AV2 (21 pin), AV3 (pin jack)
Input level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input impedance: More than 10 k≠
Audio out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output impedance: Less than 1 k≠
Digital audio out: Optical terminal (PCM, Dolby Digital, DTS, MPEG)
HDMI Output 19 pin type A: 1 pc
HDMI
TM
(V.1.3a with Deep Colour)
≥This unit supports “HDAVI Control 5” function.
Video
Video system:
SECAM (only input)/PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording system: MPEG2 (Hybrid VBR)
Video in (PAL/SECAM/NTSC):
AV1/AV2 (21 pin), AV3 (pin jack) 1 Vp-p 75 ≠, termination
S-Video in (PAL/SECAM/NTSC):
AV2 (21 pin), AV3 (S terminal) 1 Vp-p 75 ≠, termination
RGB In (PAL): AV2 (21 pin) 0.7 Vp-p (PAL) 75 ≠, termination
Video Out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 ≠, termination
RGB Out (PAL/NTSC):
AV1 (21 pin) 0.7 Vp-p (PAL) 75 ≠, termination
VHS
Recording format:
VHS Video Cassette System Standard with FM audio
Heads: 4 Helical Scan Heads for Video
2 Helical Scan Heads for FM audio
1 Fixed Head for Normal audio
Tape speed/Recording time (with E-240 tape):
PAL: SP: 23.39 mm/s, 240 min
LP: 11.7 mm/s, 480 min
EP: 7.8 mm/s, 720 min
NTSC: SP: 33.35 mm/s, 168 min
EP: 11.12 mm/s, 505 min
Television system
RF converter output: Not provided
Active Antenna output: 5 V switched, 50 mA max.,
over current protected.
SD Card
Slot: SD Memory Card slot: 1 pc
Compatible media: SD Memory Card
§4
, SDHC Memory Card
§4
,
MultiMediaCard
Format: FAT12, FAT16
§5
(In case of SD Memory Card/MultiMediaCard)
FAT32
§5
(In case of SDHC Memory Card)
Still picture (JPEG)
Format:
JPEG conforming DCF (Design rule for Camera File system)
Compatible pixels: Between 34 a 34 and 6400 a 6400
sub sampling; 4:2:2 or 4:2:0
Video (SD Video)
§6
Codec: MPEG 2 (SD-Video Entertainment Video Profile)
File Format: SD-Video format conforming
USB port Type A : 1 pc
USB standard: USB 2.0 High Speed
Format: FAT16, FAT32
Video (SD Video)
§3
Codec: MPEG 2 (SD-Video Entertainment Video Profile)
File Format: SD-Video format conforming
Others
Region code:
‚ 2
Operating temperature: 5 oC to 40 oC
Operating humidity range: 10 % to 80 % RH (no condensation)
Power supply: AC 220 to 240 V, 50 Hz
Power consumption: Approx. 41 W
Dimensions (WkHkD): 430 mmk84 mmk335 mm
(excluding the projecting parts)
430 mmk84 mmk346 mm
(including the projecting parts)
Mass: Approx. 6.1 kg
Specifications are subject to change without notice.
§1
Finalising is necessary for compatible playback.
§2
Conforming to IEC62107
This unit is not compatible with “Chaoji Video CD” available on the
market including CVD, DVCD and SVCD that do not conform to
IEC62107.
§3
Video Recording conversion and transfer is possible from
Panasonic digital video camera with HDD etc, to HDD or
DVD-RAM disc.
After Video Recording conversion and transfer to HDD or DVD-
RAM disc, the playback is possible.
§4
Includes miniSD or miniSDHC Cards. (A miniSD or miniSDHC
Adaptor needs to be inserted.)
Includes microSD or microSDHC Cards. (A microSD or microSDHC
Adaptor needs to be inserted.)
§5
Long file name is unsupported.
§6
Video Recording conversion and transfer is possible from card to
HDD or DVD-RAM disc. After Video Recording conversion and
transfer to HDD or DVD-RAM disc, the playback is possible.
≥Usable capacity will be less. (SD card)
CD 780 nm wave length
DVD 662 nm wave length
Tuner system Channel coverage
PAL-B,G,H
(CCIR)
VHF: E2–E12, A–H2 (Italy)
UHF: 21–69
CATV: S01–S05 (S1–S3),
S1–S20 (M1–U10), S21–S41
DVB-T
(Germany/Austria)
VHF: 5–12
UHF: 21–69
DVB-T
(Italy)
VHF: D–H2
UHF: 21–69
DVB-T
(Spain/Switzerland)
VHF: 5–12
UHF: 21–69
Power consumption in standby mode:
Approx. 0.5 W (“Power Save in Standby” is activated and
“RF OUT ( Aerial Signal )” is set to “Off”)
Approx. 16 W (“Power Save in Standby” is not activated.)
Note
