Panasonic Lumix DMC-FX01 User Manual

Basic
28
VQT0V86
∫ Picture size and maximum zoom
magnification
(±: Available, —: Not available)
∫ Extended optical zoom mechanism
When you set the picture size to [ ]
(3M EZ) (3 million pixels), the 6M (6 million
pixels) CCD area is cropped to the center
3M (3 million pixels) area, allowing a
picture with a higher zoom effect.
• Refer to P65 for aspect ratio settings, P65 for
picture size and P25 for simple mode [ ].
• “EZ” is an abbreviation of
[Extended optical Zoom].
• You can further enhance the zoom
magnification with the extended optical
zoom without worrying about further
picture distortion.
• If you set a picture size that activates the
extended optical zoom, the extended
optical zoom icon [ ] is displayed on the
screen when you use the zoom function.
• The zoom will stop moving for an instant
near [W] (1k) when the extended optical
zoom is used. This is not a malfunction.
• The indicated zoom magnification is an
approximation.
• In motion picture mode [ ] and
[HIGH SENS.] in scene mode, the
extended optical zoom does not work.
A maximum of 14.6k zoom can be
achieved with the 3.6k optical zoom and
the 4k digital zoom when [D.ZOOM] is set
to [ON] in the [REC] menu. However, if a
picture size that can use extended optical
zoom is selected, a maximum of 20k zoom
can be achieved with the 5k extended
optical zoom and the 4k digital zoom.
∫ Menu operation
1 Press [MENU/SET].
• When a scene mode is selected, press
2 in the [SCENE MODE] menu (P46),
press 4 to select the [REC] menu icon
[ ] and then press 1.
2 Press 3/4 to select [D.ZOOM]
and then press 1.
3 Press 4 to select [ON] and then
press [MENU/SET].
Aspect
ratio
Picture size
Maximum
zoom
magnification
Extended
optical
zoom
/(6M)
3.6k —(5M)
(4.5M)
(3M EZ)
(2M EZ)
(1M EZ)
/
(0.3M EZ)
5k±
/
(2.5M EZ)
(2M EZ)
Using the Digital Zoom
Further extending the zoom
MENU
AF MODE
AF ASSIST LAMP
SLOW SHUTTER
OFF
ON
1
/
8
㧙
AUDIO REC.
OFF
2
/
3
REC
/SET
MENU
OFF
ON
D.ZOOM
SELECT
SET
MENU
VQT0V86ENG.book 28 ページ ２００６年１月３０日 月曜日 午前９時４６分

Panasonic Lumix DMC-FX01 Specifications

General

Megapixel	6 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Supported aspect ratios	3:2, 4:3, 16:9
Digital zoom	4 x
Optical zoom	3.6 x
Focal length range	4.6 - 16.8 mm
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	8 - 1/2000 s
Focal length (35mm film equivalent)	28 - 102 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	multi point auto focus, single auto focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Flash modes	Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 3.1 m
Flash range (wide)	0.6 - 6.3 m
Motion JPEG frame rate	30 fps
Maximum video resolution	848 x 480 pixels
Display diagonal	2.5 \
I/O ports	AV
USB version	2.0
Scene modes	beach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, party (indoor), Portrait, self-portrait, Sports, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	black&white, Neutral, Sepia, Vivid
White balance	auto, Cloudy, custom modes, daylight, Shade
Camera playback	single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Black
Battery type	3.7V
Battery capacity	1150 mAh
Number of batteries supported	1
Bundled software	LUMIX Simple Viewer ArcSoft PhotoBase ArcSoft PhotoImpression ArcSoft PanoramaMaker
Compatible memory cards	mmc, sd

Weight and Dimensions

Depth	24 mm
Width	94 mm
Height	51 mm
Weight	132 g
