Panasonic Lumix DMC-LX1 User Manual

Recording pictures (basic)
31
VQT0S19
n Program AE
The camera automatically sets the shutter
speed and the aperture value according to
the brightness of the subject.
1 1 Remove the lens cap.
2 Turn the camera on.
3 Set the mode dial to program
AE mode [L].
4 Slide the focus switch to [AF].
2 Aim the AF area 1 to the point
you want to focus and then press
the shutter button halfway.
• A : Press the shutter button halfway to
focus.
• The focus indication
2 is lit and then
the aperture value
3 and the shutter
speed
4 are displayed.
• You can change the shutter speed and
aperture value with program shift (P34).
3 Take a picture.
• B : Press the shutter button fully to
take the picture.
3
2
4
When the
subject is not
focused
When the
subject is
focused
Focus
indication
Blink (green) On (green)
AF area Turns from
white to red
Turns from
white to green
Sound Beeps 4 times Beeps 2 times
P
F2.8 1/25
12
34
A

Panasonic Lumix DMC-LX1 Specifications

General

Megapixel	8.4 MP
Sensor type	CCD
Filter	Primary Color Filter
Digital zoom	22.5 x
Optical zoom	4 x
Focal length range	6.3 - 25.2 mm
Built-in flash	Yes
Dimensions (WxDxH)	105.7 x 25.6 x 55.8 mm
Camera shutter speed	60 - 1/2000 s
Focal length (35mm film equivalent)	28 - 112 mm
Internal memory	32 MB
Compatible memory cards	mmc, sd
Motion JPEG frame rate	30 fps
Maximum video resolution	848 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	207000 pixels
I/O ports	A/V Output (NTSC / PAL), USB.
Bundled software	LUMIX Simple Viewer, Photo Fun Studio, ArcSoft PhotoBase, ArcSoft PhotoImpression, ArcSoft Panorama Maker, USB Driver
Battery type	3.7 V, 1150 mAh
Product color	Black, Silver
Focus adjustment	Auto

Weight and Dimensions

Depth	25.6 mm
Width	105.7 mm
Height	55.8 mm
Weight	185 g
